1500W Laser Cutting System Laser Cutting Machine 30m/Min

Technical Class : Continuous Wave Laser

Transport Package : Wooden Pallet

Model NO. : HBS-LCT600

Specification : 1400*1700*1760mm

Laser Classification : Solid Laser

Laser Power : 500W/800W/1000W/1500W

Weight of Basic Machine : 1200kg

Repetitive Positioning Accuracy : 0.005mm

Trademark : HBS

Applicable Material : Metal

Laser Technology : Laser Vapor Cutting

Positioning Accuracy : 0.02mm

Laser Brands : Feibo / Raycus / Ipg

Working Area : 600*600mm

Power Consumption : 7kw/6.5kw/6kw/5.5kw

Laser Source : Fiber

CNC or Not : Yes (Japanese Linear Motor)

Price : US $50,000-90,000

HS Code : 84561000

Structure Type : Gantry Type

Origin : China

MOQ : 1 Set

Max. Cutting Speed : 30m/Min

Production Capacity : 100PCS/Year

Contact Now

Overview

1500W Laser Cutting System / Laser Cutting Machine is specially designed for cutting small parts in both lab testing and industrial environments. Using high-speed linear motors with marble platform gives our laser cutter the stability and acceleration needed for high-speed precision cutting. Utilizing the world top class fiber laser source, our laser cutting machine can ensure you of the best quality. Working on a variety of materials including steel, aluminum, brass, copper, titanium and alloys, our laser cutting machine provides extraordinary cutting performance and reliability.

Features
  1. 1. Fiber Laser High Efficiency and Low Operating Costs
  2. 2. Highly Stable Granite Structure
  3. 3. High-Speed Linear Motor for Faster Cutting Speed and High Precision
  4. 4. Compact Design to Reduce Facility Cost
  5. 5. Wide Range of Laser Power Selection to Reduce Your Purchasing Cost
  6. 6. Fully Enclosed System Meet CE & FDA Standards
  7. 7. Auto Stop Protection: When Cutting Head Detect Collision Between the Cutting Head and the Tilted Parts
  8. 8. Available Assist Gases for Cutting Different Materials
Specifications
Laser Brands Feibo / Raycus / IPG
Laser Source Fiber
Laser Wavelength 1064nm
Laser Power 500W/800W/1000W/1500W
Max. Cutting Speed 30m/min
CNC or not Yes (Japanese Linear Motor)
Working Area 500*500mm
Power Supply Single-Phase 220V / 3-Phase 380V (Depending on the laser source)
Positioning Accuracy ±0.02mm
Repetitive Positioning Accuracy ±0.005mm
Power Consumption 7kw/6.5kw/6kw/5.5kw
Cooling Method Water Cooling
Weight of Basic Machine 1200KG
Machine Dimension(L*W*H) 1400*1700*1760mm
Assist Gases Oxygen, Nitrogen, Compressed Air
Processable Materials Stainless steel, Carbon steel, Mild steel, Alloy steel, Silicon steel, Spring steel, Aluminum, Aluminum alloy, Galvanized sheet metal, Aluminum-zinc coated sheet metal, pickling metal, Copper, Brass, Silver, Gold, Titanium and other metals.
After-sales Service Provided Engineers available to service machinery overseas
Max. material thicknesses
1500W Laser Cutting System Laser Cutting Machine 30m/Min
Samples
1500W Laser Cutting System Laser Cutting Machine 30m/Min
Contact
1500W Laser Cutting System Laser Cutting Machine 30m/Min
